Straight Connector (Teleduct)

Straight Connector (Teleduct)

You must be logged in to be able to place orders

Characteristics:

Transparent body to enhance cable installation
Easy and fast installation – loosen slightly the nuts, insert the pipes and tighten again

Materials:

Nut, Body, Compression Ring – PP-B
Grip Ring – POM
O-Rings – NBR

Size:

16mm

20mm

25mm

32mm

40mm

50mm

63mm

Choose variant

Description
Downloads

Specially designed for Telecommunication Sector.

Performance:

Temperature
Minimum working temperature: -20 °C
Maximum working temperature: +60 °C
Max. Blowing Pressure: 16 bar
Max. Pull Out Force:
16 mm – 199 kg
20 mm – 204 kg
25 mm – 251 kg
32 mm – 310 kg
40 mm – 523 kg
50 mm – 748 kg
60 mm – 1095 kg

Characteristics:

Transparent body to enhance cable installation
Easy and fast installation – loosen slightly the nuts, insert the pipes and tighten again

Materials:

Nut, Body, Compression Ring – PP-B
Grip Ring – POM
O-Rings – NBR

Title	Type	Size	Download
FPT_Teleduct_connector.pdf	PDF	77.53KB	Download
